Oase ProfiClear Premium Standing Bed Module L

Oase ProfiClear Premium Standing Bed Module L

SKU: 87164
Brand

The ProfiClear Premium Moving Bed Module L is a biological pond filter, generally used after the automated Drum Filter Module (pump and gravity fed versions) and contains a mass of specially designed Hel-X biomedia which acts as housing for beneficial micro organisms.

£1,394.99 (inc VAT)

Be the first to leave a review.

Oase ProfiClear Premium Standing Bed Module L

The Oase ProfiClear Premium Standing Bed Module L serves as a biological filtration component designed to integrate seamlessly into ProfiClear Premium-L modular filtration systems.

Featuring a substantial quantity of static ‘ClearWave Blocks’ filtration media arranged in a densely structured, curved honeycomb-like pattern, this module offers an extensive surface area for effective biological filtration of soluble waste, pollutants, and nitrogen compounds in the water. It can be used as an alternative to the ProfiClear Premium L Individual Module in pump-fed filter systems. Installed at the end of the Oase ProfiClear Premium L modular filtration system, the ProfiClear Premium Discharge Module L enhances biological filtration.

Connecting directly to the ProfiClear Premium L Moving Bed Module through two large 150mm inlet connections on the module’s front, it releases water back to the pond via two 110mm pipe connections. The module also features an air pipe inlet and aeration element, allowing connection to an Air Pump to infuse oxygen into the ClearWave Blocks media, optimizing biological activity within the filter.

3-year Guarantee after registering your item with Oase.

Characteristics:

  • Mature, professional technology with more than three years of development time

  • Maximum flexibility in the connection through 2 x DN110 and 2″ transitions

  • Integrated bottom drain with high quality, finely engineered slide valve

  • Flexible adaptation of the filter system to individual requirements (individual module)

  • Innovative and reliable product »Made in Germany



The Full Oase Proficlear Premium L Gravity Fed Filter System Comprises of:

Oase ProfiClear Premium DF-L Gravity Fed OC

Oase ProfiClear Premium Standing Bed Module L

Oase ProfiClear Premium Moving Bed Module L

Oase ProfiClear Premium Individual Module L

2x Oase Bitron Premium 60w UVC

2x Oase Aquaamx Gravity Eco 15000



The Full Oase Proficlear Premium L Pump Fed Filter System Comprises of:

Oase ProfiClear Premium DF-L Pump Fed OC

Oase ProfiClear Premium Standing Bed Module L

Oase ProfiClear Premium Moving Bed Module L

Oase ProfiClear Premium Discharge Module L

Oase Bitron Premium 120w UVC

Oase Aquamax Eco Expert 26000



Technical Info:

Dimensions (L x W x H) mm 830 x 600 x 820
Net weight kg 44.00
Limited Warranty Years 2 + 1
Material GRP Duroplast
Number of inlets Units 2
Inlet connections mm 180
Inlet connections DN 180
Number of outlets Units 2
Outlet connections DN 150
Sludge discharge connections DN 75
Connection to AquaOxy 500
Min. flow rate l/h 10000
Max. flow rate l/h 33000
Installation height above water level cm 11.5
Type of use Pump fed system
Other Aeration pre-installed
Pollutant discharge incl. slide valve
