Oase BioSmart 36000 Pond Filter Set

SKU: 56793
GTIN: 4010052567938
Brand

Filter type

Flow through filter

Installation

Pump fed

Pond pump supplied

Yes

UVC supplied

Yes

Oase BioSmart 36000 Set. Includes AquaMax Eco Classic 11500 and 36 W Vitronic UVC. Free-flowing gravity return required.

£719.62 (inc VAT)

Oase BioSmart 36000 Pond Filter Set

Flow-through filtration with pump and 36 W UVC

The Oase BioSmart 36000 Set is a flow-through pond filter set. The 36000 set combines the larger filter housing with a 36 W Vitronic and an AquaMax Eco Classic 11500. Allow for pipe losses and the filter limit when setting the actual flow; the pump name is not the permitted flow through the filter.

A free-flowing return to the pond

Water is pumped into the filter, passes through the foams and leaves through the gravity outlet. The foams trap suspended solids and provide surfaces for biological filtration. A UVC works on suspended green-water algae; it does not replace the foams or remove settled sludge.

Install the filter on a firm, level base with its outlet positioned to drain freely back to the pond. This is not a sealed pressure filter for pumping clean water uphill from the outlet. Keep the return large enough and free of restrictions, and leave access to the lid, cleaning handles and drain.

Choose the rating for your fish load

The 36000 model name is not the same as the suitable volume for a stocked koi pond. Oase gives separate ornamental, general fish and koi ratings, shown below. Feeding, fish size, sunshine and the amount of waste entering the filter all influence the sensible choice.

Specification Details
Oase product code 56793
Manufacturer ornamental-pond rating Up to 36,000 litres
Manufacturer fish-pond rating Up to 18,000 litres
Manufacturer koi-pond rating Up to 9,000 litres
Maximum flow through the filter housing 8,000 litres/hour
Filter dimensions (L Ă— W Ă— H) 770 Ă— 555 Ă— 405 mm
Foams in the filter Nine: four blue, four red and one green
Clean-water outlet DN75 gravity return
Pump in the set AquaMax Eco Classic 11500
UVC in the set 36 W Vitronic
Hose supplied 3 m hose

Cleaning and replacement parts

The cleaning handles squeeze accumulated dirt from the foams, and the sludge outlet lets you discharge that dirty water. Check the dirt indicator and the actual pond conditions to decide when cleaning is needed. Allow a suitable waste route before fitting the filter rather than trying to carry dirty water away afterwards.

For replacement media, use the matching BioSmart replacement foams and select the correct model and colour. Where a UVC is fitted, isolate it before servicing and match replacement lamps and quartz parts to the actual Vitronic label.

If you already own compatible circulation and UVC equipment, compare BioSmart 36000 before buying a set. The BioSmart range shows the other sizes and set combinations.
