AquaForte Floating Fountain Controller and Timer

Categories:
SKU: FN122

AquaForte floating-fountain controller with remote operation, six timer positions and an adjustable pump setting. Check the exact pump and controller compatibility before installation.

£94.99 (inc VAT)

Out of stock

Out of stock

AquaForte Floating Fountain Controller and Timer

Plan fountain operating periods and adjust the pump setting from a dedicated controller

The AquaForte floating fountain controller combines remote operation, a programmable timer and an adjustable pump setting. It is a separate accessory for controlling the fountain’s operation, rather than a replacement pump or spray head. Check the controller and fountain model together when adding it to an existing installation.

Setting a daily fountain schedule

The FC-600 instructions provide six timer positions, each with an on time and an off time. Set the controller’s clock before entering the operating periods so that the programme follows the intended time of day. It is useful to write down the planned periods first, particularly when the fountain is wanted for separate morning and evening displays.

Each programmed start needs a corresponding stop. Review the complete schedule after making changes rather than checking only the last time entered. The manual also explains how to remove a period by clearing both its on and off entries. Follow the illustrated button sequence supplied with the controller when setting or deleting a programme.

Manual operation and the pump setting

The control instructions distinguish manual and timer operation, allowing the operating mode to be selected for the task. Before leaving the fountain to follow its normal schedule, check the displayed mode as well as the clock. A correctly entered programme is only part of setting up timed operation.

The manual shows an adjustable pump setting from 50% to 99%. Use changes in that setting to assess the resulting fountain display. The number on the controller is not a measurement of the water volume delivered by the pump: the resulting spray also depends on the fountain and nozzle arrangement.

Planning the fountain installation

Keep controls accessible for checking the display and changing the programme. Follow the installation requirements supplied with the fountain and controller, and check the actual electrical connections before assembly. A controller for one pump family should not be chosen only because another pump has a similar wattage or a plug that appears to fit.

Lighting is a separate consideration. The AquaForte three-light floating-fountain set is available as another accessory for the display. Check the lighting’s own power and control arrangement; a fountain pump timer should not automatically be treated as a lighting controller.

A practical way to plan your programme

For a decorative display, you might want one operating period while the garden is used in the morning and another in the evening. Write these as separate start-and-stop pairs before programming the controller. For example, a morning display from 09:00 to 11:00 and an evening display from 18:00 to 21:00 use two periods. These are planning examples, not recommended operating hours for every pond.

The right programme depends on the fountain’s role. A fountain being used as part of the pond’s aeration needs a schedule that takes the pond’s oxygen requirements into account, not simply the times at which the display is most attractive. Changing the hours of a decorative feature and changing the hours of equipment relied on by the pond can have different consequences.

Checking changes to the display

When adjusting the pump setting, change one thing at a time and observe the result. Keep the same nozzle fitted while assessing a setting so you can judge what that adjustment has done. If you change the nozzle as well, the spray pattern changes for a separate reason and the two effects become harder to compare.

Consider the pond boundary and the normal viewing position when choosing the display. A taller spray is not automatically the best arrangement for a smaller area. Keep water landing within the intended water surface, and review the fountain’s position and operation when weather conditions change. The controller does not alter the physical shape of the nozzle or the space available around the fountain.

Keeping your settings easy to maintain

Keep a short record of the chosen operating periods beside the fountain’s documentation. If another person maintains the pond, that record helps them distinguish the intended schedule from a temporary manual change. After a power interruption or seasonal restart, check the displayed clock, mode and programme before relying on timed operation.

Use the AquaForte FC-600 controller instructions for the illustrated button sequences. The instructions for a different AquaForte controller may use a different layout or operating method, so keep the correct document with this unit. The separate fountain manual remains the reference for the pump, float, nozzle and mooring arrangement.
