Oase Bitron C 24 Watt UVC

Oase Bitron C 24 Watt UVC

Self Cleaning UV Clarifier for Clear and Healthy Pond Water

The Oase Bitron C 24 Watt UVC is a high performance ultraviolet clarifier designed to eliminate green water and reduce harmful bacteria in ponds up to 25000 litres. It targets suspended algae directly and, as a result, restores water clarity while supporting a healthier aquatic environment.

Unlike basic UV units, the Bitron C 24W features a patented automatic cleaning rotor. As water flows through the unit, the rotor continuously moves around the quartz sleeve. Consequently, it prevents debris and limescale from settling on the glass, which ensures the UV output remains strong and consistent.

The integrated bypass system allows high flow rates while maintaining optimal irradiation time. Because of this design, up to 3500 litres per hour can pass the UV tube without bypassing the radiation zone. In addition, you can adjust the flow individually using the built in throttle handle to match your pump and filter setup.

The unit includes a clear inspection window, so you can check the bulb at any time. Furthermore, the intelligent function monitor indicates bulb operation and reminds you when a replacement is required. Integrated magnets also help protect the UV technology from limescale build up, which improves long term reliability.

Safety remains a priority. The quick release closure allows easy bulb access, while a built in safety switch automatically deactivates the UV lamp when opened. Therefore, it prevents accidental exposure and meets strict VDE safety standards.

The Bitron C 24 Watt works particularly well with Oase flow through filters such as the BioSmart 18000 and 36000. When paired with compatible Oase filtration systems including BioSmart, BioTec and ProfiClear, it qualifies for the Oase Clear Water Guarantee.

Key Benefits

• Suitable for ponds up to 25000 litres
• Eliminates green water caused by suspended algae
• Reduces harmful bacteria and pathogen levels
• Patented automatic cleaning rotor
• Clever bypass system for high flow with optimal irradiation
• Adjustable water flow control
• Inspection window for visual bulb check
• Integrated limescale protection magnets
• Quick release closure for easy bulb replacement
• VDE certified safety system
• Compatible with BioSmart, BioTec and ProfiClear filters

Technical Specifications

• Maximum pond size: 25000 litres
• Recommended pond capacity
• Low fish stock and low sunlight: 14180 litres
• High fish stock and high sunlight: 7630 litres
• UVC power: 24 watts
• Maximum flow rate without bypass: 3500 litres per hour
• Connections: universal stepped hose tail 25 mm to 38 mm
• Cable length: 5 metres
• Voltage: 230 V 50 Hz
• Housing: impact resistant plastic
• Cleaning system: automatic rotor

Technical information

UV sizing and maintenance notes

Oase Bitron C 24 Watt UVC should be matched to the pond volume, flow rate and water clarity problem you are trying to solve. UV clarification works best when water passes the lamp at a suitable speed and the quartz sleeve is kept clean. If the flow is too fast, contact time can be reduced. If the lamp is old or the quartz sleeve is dirty, performance can drop even when the unit still appears to be switched on.

• Replace UV lamps as part of routine seasonal maintenance.
• Clean or inspect the quartz sleeve when water clarity starts to deteriorate.
• Match the UV to the pump and filter rather than installing it in isolation.
• Allow safe access for lamp changes and winter maintenance.

Good UV performance also depends on mechanical filtration. Removing fine debris before the UV helps the lamp work on green water algae more effectively.
