Poolex Megaline Fi Inverter Commercial Pool Heat Pump

Poolex Megaline Fi Commercial Pool Heat Pump

High-performance commercial swimming pool heating with advanced inverter efficiency

The Poolex Megaline Fi range has been developed specifically for commercial swimming pools, leisure centres, hotels, therapy pools, holiday parks, and large residential installations where heating costs can become significant.

Using advanced stepless DC inverter technology, the heat pump automatically adjusts compressor and fan speeds according to heating demand. This intelligent modulation significantly reduces electricity consumption while maintaining stable pool temperatures and quieter operation.

The vertical air discharge system reduces acoustic pressure while requiring minimal installation space, making the Megaline Fi suitable for plant rooms and compact technical areas.

Integrated Wi-Fi connectivity allows users to remotely monitor and control system performance using the Smart Life mobile app.

Commercial-Grade Construction and Reliable Performance

The Megaline Fi range is constructed using high-quality stainless steel structural components combined with a powder-coated galvanised steel cabinet for long-term durability in demanding environments.

Each model is equipped with Mitsubishi multi-frequency rotary inverter compressors and DC brushless fan motors to maximise performance, reliability, and energy efficiency.

The Twisted Titanium heat exchanger offers excellent resistance against chlorine and salt-treated pool water, helping ensure long service life in both commercial and intensive-use swimming pools.

The range operates efficiently in outdoor temperatures down to -15°C thanks to automatic hot gas defrost technology, extending pool usage throughout the year.

Intelligent Heating and Cooling Modes

The Poolex Megaline Fi range includes multiple operating modes to suit changing environmental conditions and pool requirements.

Available operating modes include:

• Heating mode
• Cooling mode
• Silence mode
• Automatic mode

The adjustable temperature range allows accurate water temperature management for both heating and cooling applications.

Heating range: 15°C to 40°C
Cooling range: 8°C to 28°C

Smart Controls and Wi-Fi Connectivity

The Megaline Fi range features a high-end multilingual colour LCD touch screen controller designed for simple commercial operation.

The display provides:

• Operating status information
• Temperature settings
• System parameters
• Error codes
• Performance monitoring

Built-in Wi-Fi connectivity enables remote control and monitoring through the Smart Life smartphone app.

Energy-Efficient Commercial Pool Heating

The advanced inverter management system continuously regulates compressor and airflow output based on real-time heating demand.

This intelligent operation helps:

• Reduce energy consumption
• Lower operating costs
• Improve seasonal efficiency
• Minimise compressor stress
• Reduce operating noise

The Megaline Fi range delivers exceptionally high COP performance, helping commercial operators reduce long-term heating expenses.

Installation and Water Connections

All models within the Poolex Megaline Fi range are three-phase units and require installation by a qualified electrician.

Water connections:

• Fi 35: 63mm
• Fi 50 / Fi 70 / Fi 100: 75mm

The units are supplied with unions suitable for pressure pipe installations.

A bypass kit is recommended to optimise water flow, improve heat transfer efficiency, and simplify maintenance or winterisation procedures.

Available Models

Poolex Megaline Fi 35

The Fi 35 model is ideal for medium-sized commercial pools and intensive residential installations requiring efficient all-season heating.

Key specifications include:

• Maximum heating capacity (A26/W26): 42.50kW
• Heating capacity (A15/W26): 35kW
• COP up to 11.46
• Maximum power consumption: 9.5kW
• Noise level: <47dB
• Weight: 175kg

Poolex Megaline Fi 50

The Fi 50 model delivers increased heating performance for larger commercial swimming pools and leisure facilities.

Key specifications include:

• Maximum heating capacity (A26/W26): 63.34kW
• Heating capacity (A15/W26): 50kW
• COP up to 13.06
• Maximum power consumption: 14.9kW
• Noise level: <48dB
• Weight: 225kg

Poolex Megaline Fi 70

The Fi 70 model is designed for demanding commercial pool heating applications with larger water volumes and continuous operation requirements.

Key specifications include:

• Maximum heating capacity (A26/W26): 89.80kW
• Heating capacity (A15/W26): 70kW
• COP up to 15.93
• Maximum power consumption: 20kW
• Noise level: <50dB
• Weight: 448kg

Poolex Megaline Fi 100

The Fi 100 model provides maximum heating performance for large public pools, leisure centres, and commercial aquatic facilities.

Key specifications include:

• Maximum heating capacity (A26/W26): 135kW
• Heating capacity (A15/W26): 100kW
• COP up to 13.59
• Maximum power consumption: 29.8kW
• Noise level: <54dB
• Weight: 760kg

---

What’s Included

• Poolex Megaline Fi Heat Pump
• Pressure pipe unions
• Integrated touch screen controller
• Built-in Wi-Fi functionality
• User manuals

---

Key Benefits

• Commercial-grade inverter pool heating
• Mitsubishi rotary inverter compressors
• Integrated Wi-Fi connectivity
• Vertical low-noise ventilation design
• Stainless steel internal structure
• Twisted Titanium heat exchanger
• Heating and cooling functionality
• Operates down to -15°C
• Intelligent DC inverter power management
• Suitable for large commercial pools
• Smart Life app compatibility
• High seasonal energy efficiency

---

Technical Specifications

Type: Inverter heat pump (Commercial high-capacity pool heater)
Models: Fi 35, Fi 50, Fi 70, Fi 100
Maximum Heating Capacity (A26/W26): 42.50kW / 63.34kW / 89.80kW / 135kW
Maximum Heating Capacity (A15/W26): 35kW / 50kW / 70kW / 100kW
COP (A26/W26): 11.46–5.79 / 13.06–5.91 / 15.93–6.61 / 13.59–6.98
COP (A15/W26): 7.46–4.80 / 7.93–4.76 / 7.65–5.05 / 7.58–4.99
Operating Temperature Range: -15°C to 43°C
Heating Range: 15°C to 40°C
Cooling Range: 8°C to 28°C

Maximum Power Input: 9.5kW / 14.9kW / 20kW / 29.8kW
Voltage: 380–415V (Three Phase)
Refrigerant: R32
Wi-Fi Connectivity: Built-in (Smart Life App compatible)
Noise Level (10m): <47–54dB (depending on model)
Water Connections: 63mm / 75mm (depending on model)
Weight: 175kg / 225kg / 448kg / 760kg

Construction: Heavy-duty commercial steel housing
Heat Exchanger: High-efficiency spiral titanium heat exchanger
Compressor: Industrial DC inverter compressor system
Fan System: Variable-speed low-noise axial fans
Control: Advanced digital controller with Wi-Fi remote management
Installation: Professional installation required (three-phase commercial system)

---

Warranty Information

The Poolex Megaline Fi range includes comprehensive manufacturer warranty coverage:

• Heat Pump: 3 years parts and labour
• Compressor: 7 years
• Titanium Heat Exchanger: 15 years against corrosion

(Parts only after year three for compressor and heat exchanger coverage.)

---

Understanding COP Efficiency

COP stands for Coefficient of Performance and measures the heating efficiency of a heat pump.

A COP of 15.93 means the heat pump can produce up to 15.93kW of heating energy for every 1kW of electricity consumed under specific operating conditions.

Higher COP values help reduce energy consumption and long-term operating costs.

---

Important Notes

• Suitable for commercial and public swimming pools
• Three-phase electrical supply required
• Professional installation is required
• Wi-Fi requires stable network coverage
• Performance varies depending on ambient conditions
• Bypass kits are recommended for optimal flow regulation
• Seasonal efficiency depends on pool insulation and environmental conditions
